MB MSI MAG Z790 TOMAHAWK WIFI

Performance-ready Z790 ATX motherboard with Wi‑Fi 6E The MSI MAG Z790 TOMAHAWK WIFI is an ATX Intel Z790 motherboard for LGA 1700 systems, featuring DDR5 memory support, quad M.2 storage and onboard Intel Wi‑Fi 6E with Bluetooth 5.3.

Key Features:

• Chipset and CPU support: Enables 12th, 13th and 14th Gen Intel Core, plus Intel Pentium Gold and Celeron processors on LGA 1700 for broad platform compatibility.

• High-speed memory: Four DDR5 DIMM slots with Memory Boost and wide OC frequency range to maximize system responsiveness and overclocking headroom.

• Quad M.2 storage: Four M.2 slots including a CPU-mounted PCIe 4.0 x4 socket plus three chipset M.2s for multiple high-performance NVMe drives.

• Advanced connectivity: Integrated Intel Wi‑Fi 6E, Bluetooth 5.3 and Intel 2.5Gbps LAN provide fast wireless and wired networking for gaming and content tasks.

• Future-ready PCIe: Primary PCIe x16 slot supports PCIe 5.0 (Lightning Gen 5) while additional slots offer PCIe 4.0 and Gen3 connectivity for expansion cards.

Technical Specifications:

• Chipset: Intel Z790

• Socket: LGA 1700

• Form Factor: ATX 243.84mm x 304.8mm

• Memory Support: 4x DDR5 DIMMs, Dual-Channel

• Max Memory: 256GB

• M.2 Slots: 4x M.2 (M.2_1 CPU: PCIe 4.0 x4 22110/2280/2260; M.2_2/3/4 Chipset: up to PCIe 4.0 x4; M.2_3 supports SATA)

• PCIe Slots: 2x PCIe x16 (PCI_E1 Gen5 x16 from CPU; PCI_E3 Gen4 x4 from Chipset) + 1x PCIe x1 (Gen3 from Chipset)

• Networking: Intel 2.5Gbps LAN; Intel Wi‑Fi 6E (pre-installed M.2 Key‑E module), Bluetooth 5.3

• Rear I/O: DisplayPort 1.4, HDMI 2.1, Clear CMOS, Flash BIOS Button, Optical S/PDIF OUT, Wi‑Fi antenna ports

• Audio: Realtek ALC4080 codec — 7.1‑Channel, Audio Boost 5, S/PDIF out, up to 32‑bit/384kHz playback (front)
