Gigabyte B860M EAGLE PLUS WIFI 6E Motherboard – Intel B860, DDR5, WiFi 6E, Micro-ATX

The Gigabyte B860M EAGLE PLUS WIFI 6E is a reliable micro-ATX motherboard designed for mainstream gamers, professionals, and PC builders who want stability and modern features at an accessible price point. Built on the Intel B860 chipset, it supports 12th, 13th, and 14th Gen Intel Core processors on the LGA 1700 socket, offering excellent performance for gaming and productivity builds.

Equipped with support for DDR5 memory, this board provides higher speeds and improved efficiency for smoother multitasking and faster system responsiveness. With a PCIe 4.0 x16 slot, it ensures compatibility with current-generation graphics cards, while dual M.2 PCIe Gen4 NVMe slots offer fast storage expansion for SSDs.

One of the highlights of the EAGLE PLUS WIFI 6E is its built-in WiFi 6E and 2.5Gb Ethernet, which deliver stable, low-latency connections whether you’re gaming online, streaming, or working. Gigabyte’s Ultra Durable components and thermal design with enlarged heatsinks guarantee long-term stability.

For connectivity, it includes USB 3.2 Gen2 Type-C, HDMI, and DisplayPort outputs, giving flexibility for both workstations and gaming setups. With RGB Fusion software, users can customize lighting effects to match their system’s style.

Balancing affordability, stability, and modern technology, the Gigabyte B860M EAGLE PLUS WIFI 6E is an excellent choice for builders who want strong performance and next-gen connectivity in a micro-ATX design.

⭐ Key Features

• Supports Intel 12th / 13th / 14th Gen CPUs (LGA 1700)

• Intel B860 chipset (mainstream performance)

• DDR5 memory support up to high frequencies

• PCIe 4.0 x16 slot for modern GPUs

• Dual NVMe M.2 slots (Gen4) for fast SSDs

• WiFi 6E + 2.5Gb Ethernet networking

• USB 3.2 Gen2 Type-C, HDMI, DisplayPort

• Ultra Durable components & enlarged heatsinks

• RGB Fusion lighting control

• Micro-ATX form factor

⚙️ Specifications

• Chipset: Intel B860

• Socket: LGA 1700 (Intel 12th/13th/14th Gen CPUs)

• Form Factor: Micro-ATX

• Memory: 4 × DDR5 DIMM slots, up to 192GB, 7200MHz (OC)

• Expansion: 1 × PCIe 4.0 x16, 1 × PCIe 3.0 x16 (x4), 1 × PCIe 3.0 x1

• Storage: 2 × M.2 (PCIe Gen4 x4), 4 × SATA 6Gb/s

• Networking: Intel 2.5Gb LAN, WiFi 6E, Bluetooth 5.3

• USB Ports: USB 3.2 Gen2 Type-C, USB 3.2 Gen2, USB 3.2 Gen1, USB 2.0

• Audio: Realtek 7.1 Channel HD Audio

• Power Design: Optimized VRM with durable MOSFETs

• Warranty: 3 Years Limited.
