ASUS TUF GAMING A520M-PLUS WIFI Motherboard AM4

Durable microATX AM4 motherboard with onboard Wi‑Fi The ASUS TUF GAMING A520M-PLUS WIFI AM4 is an AMD A520 microATX motherboard with AM4 socket, onboard Wi‑Fi 5 and Bluetooth 5.0, and DDR4 memory support for building compact Ryzen systems.

Key Features:

• Built for Ryzen AM4: Supports Ryzen 5000/4000 G‑Series/3000 Series processors for wide CPU compatibility.

• Onboard Wi‑Fi & Bluetooth: Realtek 8821CE Wi‑Fi 5 with MU‑MIMO and Bluetooth 5.0 provides wireless connectivity without an adapter; removable antenna included.

• Fast NVMe storage: M.2 PCIe 3.0 x4 support delivers up to 32 Gbps for quick boot and load times with compatible NVMe drives.

• TUF durability: Military‑grade TUF chokes and capacitors plus TUF LANGuard and stainless‑steel back I/O enhance longevity and reliability.

• Compact expandability: microATX layout with a full‑length PCIe x16 slot and extra PCIe x1 slots for cards in small builds.

• ASUS ecosystem: Aura Sync RGB and Addressable Gen2 headers plus Armoury Crate support for lighting and system control.

Technical Specifications:

• Chipset: AMD A520

• Socket: AMD AM4 (supports Ryzen 5000/4000 G-Series/3000 Series)

• Form Factor: microATX

• Memory Support: DDR4, 4 x DIMM, dual-channel; supported speeds up to DDR4-4800 (OC) / 3200/3000/2666/2400/2133 MHz (see ASUS QVL)

• Max Memory: 128 GB

• M.2 Slots: 1 x M.2 (Key M) 2242/2260/2280, supports PCIe 3.0 x4 & SATA mode (up to 32 Gbps)

• PCIe Slots: 1 x PCIe 3.0 x16, 2 x PCIe 3.0 x1

• Networking: Realtek 1 Gb Ethernet; Realtek Wi‑Fi 5 (8821CE) 1x1 802.11a/b/g/n/ac (2.4/5 GHz), MU‑MIMO; Bluetooth v5.0

• Rear I/O: 4 x USB 3.2 Gen 1 (Type‑A), 2 x USB 2.0 (Type‑A)

• SATA: 4 x SATA 6 Gb/s

• Video Outputs: 1 x DisplayPort 1.2, 1 x HDMI 2.1 (4K@60Hz), 1 x D‑Sub (VGA)
